![]() Paper Grade:Creped tissue paper Range of Basis Weight:11 ~ 20g/m² on dryer Machine Width: 2900 mm Mechanical Design Speed:1250 m/min Balance Speed:1250 m/min Max. Drive Speed:1250 m/min Max. Operating Speed :1200 m/min Production Capacity:55 ton /day on dryer Raw Material:LBKP, NBKP Layout:Left hand machine (Drive is on left hand side viewing from headbox on reel) |
Main models: 787, 1200, 1092, 1575, 1760, 1880, 2100, 2850, 3500.
Main structures: forming section, drying section, wrinkling and reeling section.
Model selection: mold single dryer machine, pressure former machine, vacuum suction mold machine, fourdrinier forming machine, crescent high-speed machine, etc.
Paper Grade:Creped tissue paper
Range of Basis Weight:11 ~ 20 g/m² on dryer
Main 11.3 g/m2 on dryer (24% crepe ratio)
Main 12.1 g/m2 on dryer (28% crepe ratio)
Machine Width
Headbox pond width:2900 mm
Wire width:2930 mm
Paper width:2900 mm on wire
2880 mm on dryer & reel
Paper Machine Speed
Mechanical design speed:1250 m/min
Balance speed:1250 m/min
Max. drive speed:1250 m/min
Max. operating speed :1200 m/min
Production Capacity:55 AD ton /day on dryer
Raw Material:LBKP, NBKP
Layout:Left hand machine (Drive is on left hand side viewing from headbox on reel)
PRODUCT DESCRIPTION
Main models: 787, 1200, 1092, 1575, 1760, 1880, 2100, 2850, 3500.
Main structures: forming section, drying section, wrinkling and reeling section.
Model selection: mold single dryer machine, pressure former machine, vacuum suction mold machine, fourdrinier forming machine, crescent high-speed machine, etc.
