Product variety: A-grade box board paper, kraft cardboard Quantitative range: 90~280g/m2 Annual production: customized Width: 1092-5600mm Working speed: 200-1500m/min Balance level: drying cylinder G4 roller G2.5 Transmission method: AC motor, variable frequency control, and segmented transmission Layout method: single or double layer, left/right machine layout (customized) |
Main models: 1092, 1575, 1760, 1880, 2100, 2400, 3800, 4000, 4200, 4600, 4800, 5000, 5200, 5600, etc. Single dryer and cylinder mold machine, multi dryer and cylinder mold machine, single/multiple wire machine series
Head box → triple wire section → double felt vacuum press→ jumbo roll double felt press → jumbo roll single felt press → 32 sets of Ф1800 dryer, sizing machine [arranged as 8+8+8+sizing machine+8] → 2-roll calendar → B/M gage reserved → horizontal pneumatic pope reel
Feeding consistence of head box: 0.5~1.0%
Shrinkage of sheet web: up to 4.5%
Dryness of Each Section:
Outside wire section: 18-22%
Outside press section: 45~48%
Into sizing machine: 88-92±1.5%
Finished paper: 92±1.5%
Designed and Used Linear Pressure of Press Section:
Vacuum pre-press, designed pressure 100KN/M, used pressure 80KN/M
1st wide nip press, designed pressure 280KN/M, used pressure 220KN/M
2nd press, designed pressure 280KN/M, used pressure 250KN/M
Sizing machine, designed pressure 80KN/M, used pressure 40~60KN/M
Transverse GSM tolerance: ±1.5%
Product variety: A-grade box board paper, kraft cardboard
Quantitative range: 90~280g/m2
Annual production: customized
Width: 1092-5600mm
Working speed: 200-1500m/min
Balance level: drying cylinder G4 roller G2.5
Transmission method: AC motor, variable frequency control, and segmented transmission
Layout method: single or double layer, left/right machine layout (customized)
Main models: 1092, 1575, 1760, 1880, 2100, 2400, 3800, 4000, 4200, 4600, 4800, 5000, 5200, 5600, etc. Single dryer and cylinder mold machine, multi dryer and cylinder mold machine, single/multiple wire machine series
Head box → triple wire section → double felt vacuum press→ jumbo roll double felt press → jumbo roll single felt press → 32 sets of Ф1800 dryer, sizing machine [arranged as 8+8+8+sizing machine+8] → 2-roll calendar → B/M gage reserved → horizontal pneumatic pope reel
Feeding consistence of head box: 0.5~1.0%
Shrinkage of sheet web: up to 4.5%
Dryness of Each Section:
Outside wire section: 18-22%
Outside press section: 45~48%
Into sizing machine: 88-92±1.5%
Finished paper: 92±1.5%
Designed and Used Linear Pressure of Press Section:
Vacuum pre-press, designed pressure 100KN/M, used pressure 80KN/M
1st wide nip press, designed pressure 280KN/M, used pressure 220KN/M
2nd press, designed pressure 280KN/M, used pressure 250KN/M
Sizing machine, designed pressure 80KN/M, used pressure 40~60KN/M
Transverse GSM tolerance: ±1.5%
